Blast furnace for nickel pig iron smelting
Detail



There are two pyrometallurgical smelting methods, one is blast furnace, another is electric furnace(submerged arc furnace),the process of RKEF smelting include drying, preheating, roasting, then produce nickel slag after smelting reduction. The method of blast furnace smelting require good performance of air permeability, low stock column, so the furnace can run smoothly. The blast furnace will reduce nickel oxide to metal nickel, the nickel content of ferronickel depends on raw material and reducing capacity during the reduction process, nickel pig iron smelting blast furnace use coke as reducing agent, limestone as catalyst.


HIGH EFFICIENCY AND LONGEVITY TECHNOLOGIES OF BLAST FURNACE

  • Cooling wall longevity technology

  • Blast furnace belly, furnace bosh, lower furnace shaft adopt copper cooling wall structure

  • Full cooling brick wall is integrated thin-wall furnace lining structure.

  • Choose high quality refractory material for different locations of blast furnaces

  • Blast furnace design optimization and logical furnace type

  • Appropriate furnace hearth height and tap-hole depth

  • Furnace hearth and bottom inner lining structure

  • Sub-sectional cooling in vertical direction according to thermal load at different parts of furnace.


HOT AIR STOVE TECHNICAL FEATURES

  • The vault of hot air stoves has stable structure and rational air flow distribution

  • Choose appropriate refractory materials for different work zones of hot air stove

  • Fully utilization of blast furnace coal gas, low calorific value gas can be used for hot air stoves and power generation.

  • The coal gas adopts low temperature preheating technology, safely and effectively recycle the waste heat of flue gas.

BLAST FURNACE GAS DEDUSTING TECHNOLOGY

  • Gravity de-dusting for crude gas initial processing

  • High-efficiency and low-consumption dust conveyor.

  • Pulse type nitrogen backflow system

  • Automatic control system

  • Coal gas cut-off valve assembly can turn off coal gas at both ends of dust collector, then maintain, overhaul, change filter bag, etc.

  • Raw coal gas and purified gas pipeline system

  • Ash discharging and convey system
